Send InquiryVial Capping Machine
Product Details:
- Material SS 304
- Feature Chemical Food Medical
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
Vial Capping Machine Price And Quantity
- 1 Unit
- 100000.00 - 200000.00 INR
Vial Capping Machine Product Specifications
- SS 304
- Human Machine Interface
- Silver
- Semi-Automatic
- 1000x600x950 Millimeter (mm)
- Chemical Food Medical
- 1 Year
- 100-200 Kilograms (kg)
- No
- Electric
- 220 Volt (v)
- 380 Volt (v)
Vial Capping Machine Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Australia Eastern Europe Western Europe Middle East Africa Central America South America Asia North America
- All India
Product Description
Established ourselves as a reputed manufacturer and supplier in the functional domain, we are engrossed in offering excellent quality Vial Capping Machine. Widely known for its unmatched functionality and strong design, this machine is used for sealing of aluminum caps on vials. This machine is manufactured under the stern observation of our professionals using optimum grade components and progressive technology in sync with set market quality standards. Clients can avail this Vial Capping Machine from us in diverse specifications according to their specific needs at affordable prices.
Features:
-
Robust construction
-
Long operational life
-
Precisely engineered
-
Easy to operate
-
Complete cGMP model.
-
No Seal in Chute Machine Stop system.
-
No Stopper on Vial before Sealing Machine Stop system.
-
Single motor synchronizes conveyor, starwheels and platform turret and speed can be varied by the speed pot on operating panel.
-
Parts coming in contact with the vial/aluminium cap/exposed to the atmosphere are made out of stainless steel for good housekeeping & GMP accordance.
-
Spring loaded free spinning sealing rollers eliminates any damage to aluminium caps and also allows greater flexibility of variation in the container neck diameter.
-
Sealing Pressure can be varied to suit different gauges and sizes of aluminium caps.
-
Variable A.C. frequency drive for speed adjustment.
-
Digital Counter for counting number of sealed vials
-
Photo sensing device stop machine automatically in the event of no aluminium cap in delivery chute
-
A Special clutch device is incorporated on the infeed worm and Starwheel system for stoppage of machine in the event, vial is over turned or over diameter.
-
Acrylic Cabinet with Aluminium Structure for Machine.
-
Programmable Logic Control with GUI. (Optional)
Technical Specification:
|
Model |
ACS-120 |
|
No. of Sealing Head |
Four |
|
Production Rate |
60 to 120 Vials/Minute |
|
Input Specification Container Diameter: Container Height: Cap Diameter: |
15mm to 80mm 20mm to 180mm 13mm, 20mm & 28mm with the help of change parts. |
|
Power Supply |
0.5 H.P. |
|
Electrical characteristics |
440 Volts, 3 Phase, 50 Hertz, 4 Wire System |
|
Optional Accessories |
Aluminum profile cabinet covering full machine Chuck for flip-off seal PLC with GUI |
|
Overall Dimension |
1370mm X 850mm (W) X 1800mm (H) |
Note: Electrical characteristics can be adjusted as per customers requirements.
