Send InquiryLinear Vial Washer
Product Details:
- Material Stainless Steel
- Computerized No
- Voltage 50 Volt (v)
- Power 220 Volt (v)
- Weight (kg) 100-200 Kilograms (kg)
- Dimension (L*W*H) 700 x 500 x 725 Millimeter (mm)
- Color Sliver
Linear Vial Washer Price And Quantity
- 3.7500000 INR
- 1 Unit
Linear Vial Washer Product Specifications
- No
- 1 Year
- Stainless Steel
- Sliver
- 100-200 Kilograms (kg)
- 220 Volt (v)
- 50 Volt (v)
- 700 x 500 x 725 Millimeter (mm)
Linear Vial Washer Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America Eastern Europe Africa Central America Middle East South America Asia
- All India
Product Description
Automatic Linear Vial Washer
Automatic Linear Vial Washer is uses for the washing of pharmaceutical glass vials. We are having two different models of vial washer which provided output of 120 vials per minute and 240 vials per minute. These models are most suitable for the online untouched vial filling production line.
Salient Features
- Compact c GMP model.
- Provides production output up to 250 vials per minute.
- All contact parts made from high quality stainless steel AISI SS 316L.
- Machine structure & other parts made from AISI SS 304
- SS Tanks & trays made from SS 316L by argon welded with round corner.
- SS pump made from SS 316L with mechanical seal Mono block pump.
- SS filter housing made from SS 316L.
- All Nozzles made from SS 316L.
- Special Pocket system ensures easy and trouble free washing of vials from outer and inner side.
- Indexing motion makes easier for syringes to move inside vial, when it is in stationery motion.
- No Change parts are required from 5 ml to 30 ml vial.
- Washing cycles can be adjusted as per customer requirement.
- User friendly machine, even semi skilled operator can operate the machine very easily.
- A Special clutch device is incorporated for Stoppage of Machine in the event; vial is over turned or over diameter.
- Variable A.C. Frequency drive for Main drive and conveyor.
- Pumps with tank (60 litres each) 2 nos.
- In feed Wire Woven Belt for feeding of Vials.
- HDPE material Vial pockets.
- Machine is totally robust and withstands continues operation for long working hours without any trouble.
- Machine is equipped with PLC system & printing facility with passwords.
Technical Specification:
| Description | AVW-120 | AVW-250 |
| Production Rate | 120 vials/minute | 250 vials/minute |
| Vial Size | 2ml to 250ml | 2ml to 250ml |
| Direction | Left to right | Left to right |
| Height of conveyor | 850mm to 900 | 850mm to 900mm |
| Power Supply (Main Machine) | 1 H.P. | 1.5 H.P. |
| Power Supply (Pumps) | 2 H.P. | 2 H.P. |
| Power Supply (Conveyor) | 0.5 H.P. | 0.5 H.P. |
| Electrical Characteristics | 440 Volts, 3 Phase, 50 Hertz | 440 Volts, 3 Phase, 50 Hertz |
| tility (Air) | 20 CFM | 20 CFM |
| Utility (Water) | 400 Liters/hour | 600 Liters/hour |
| Overall Dimension | 2290mm (L) X 1175mm (W) X 1575mm (H) | 3500mm (L) x 1500mm (W) x 1675mm (H) |
| Net Weight | 1000 kgs. | 1200 kgs. |
