Send InquiryAutomatic Screw Capping Machine
Product Details:
- Material SS 304
- Feature Food Medical Chemical
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
Automatic Screw Capping Machine Price And Quantity
- 1 Unit
- 300000 INR
Automatic Screw Capping Machine Product Specifications
- 100-200 Kilograms (kg)
- Human Machine Interface
- Food Medical Chemical
- 380 Volt (v)
- Silver
- Electric
- 1000x600x950 Millimeter (mm)
- 220 Volt (v)
- No
- Semi-Automatic
- SS 304
- 1 Year
Automatic Screw Capping Machine Trade Information
- Nhava Sheva
- Cash Advance (CA) Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America Eastern Europe Central America Africa Middle East South America Asia
- All India
Product Description
To cater wide needs of our valuable clients, we are instrumental in manufacturing and supplying outstanding quality Automatic Screw Capping Machine. This machine is manufactured at our sophisticated production unit using excellent quality components and advanced machines as per defined industry norms. Provided machine finds wide application in food, pharmaceutical, cosmetic and other similar industry. Moreover, the provided Automatic Screw Capping Machine in several specifications to meet clients exact need.
Features:
-
Excellent performance
-
Noise-free operations
-
Low power consumption
-
Require less maintenance
Automatic Screw Capping Machine
Automatic Screw Capping Machine is suitable for round or other shape of glass, plastic, PET, LDPE, HDPE bottles. Machine constructed in stainless steel finish including M.S. frame structure with stainless steel cladding/enclosures. The capping machine is ideal for application in pharmaceutical, food, pesticides, cosmetic & other Industries.
Salient Features :
-
Compact GMP model.
-
No Bottle No Cap system.
-
No Cap in Chute Machine Stop system.
-
Container Overturn Machine Stop mechanism.
-
Inbuilt pulse counter.
-
Quick and very easy change over and setting from one size of Container to another by a Single Ratchet.
-
Parts coming in contact with the Container or the Aluminum cap or exposed to atmosphere are made out of stainless steel for long life.
-
Single motor synchronizes Conveyor, star wheel and Platform Turret and speed can be varied by VFD.
-
Star Wheel is equipped with safety clutch for automatic stoppage of machine in case of jamming or overloading.
-
Digital counter for counting production output.
Technical Specification :
|
Model |
ACSS-60 |
|
No. of Capping Heads |
Single |
|
Production Rate |
30 to 60 Containers/Minute |
|
Input Specification Container Diameter: Container Height: Cap Diameter: |
24mm to 90mm 50mm to 250mm 20mm, 25mm & 28mm with the help of change parts |
|
Power Specification: |
1 H.P. |
|
Electrical characteristics |
440 Volts, 3 Phase, 50 Hertz, 4 Wire System |
|
Conveyor Height |
800mm to 900mm adjustable |
|
Optional Accessories |
Aluminum profile cabinet covering full machine PLC with GUI |
|
Overall Dimension |
1500mm (L) X 850mm (W) X 1800mm (H) |
Note: Electrical characteristics can be adjusted as per customer's requirements.
