Send InquiryAutomatic Dry Syrup Filling Machine
Product Details:
- Material SS 304
- Capacity 5000 Kg/hr
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 0.5 Volt (v)
250000 INR
X
Automatic Dry Syrup Filling Machine Price And Quantity
- 250000 INR
- 1 Unit
Automatic Dry Syrup Filling Machine Product Specifications
- Silver
- 0.5 Volt (v)
- SS 304
- 100-200 Kilograms (kg)
- 1 Year
- No
- 400 x 600 x 500 Millimeter (mm)
- Electric
- 240 Volt (v)
- Semi-Automatic
- Human Machine Interface
- 5000 Kg/hr
Automatic Dry Syrup Filling Machine Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Cash Advance (CA) Telegraphic Transfer (T/T) Cash in Advance (CID)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Middle East Central America Eastern Europe Africa South America Australia Asia North America
- All India
Product Description
Automatic Dry Syrup Filling Machine
Automatic Single Wheel Dry Syrup Powder Filling Machines for filling of large volume powder into containers. Machine is widely uses in pharmaceutical, cosmetic, veterinary, herbal & food industries.
Salient Features:
- No Container - No Filling system eliminates wastage of costly powders
- Machine can be operated in Single Stroke to Four Stroke and provide output up to 50 fills per minute with an accuracy of ±2% depending upon powder type and fill size.
- All the parts which are coming in contact with the product are made out of S.S 316L material and easily Removable for mandatory autoclaving/sterilization.
- Totally enclosed heavy steel structure body to avoid any vibration.
- Variable AC Frequency drive to control the speed of the conveyor.
- Endless conveyor belt to prevent jamming of assembly due to spillage of powder.
Process Operation:
The incoming sterilized dry bottle is fed through the in-feed turn table. Suitable guide supply bottles on to flat conveyor belt at the required speed for feeding. There is filling head mounted on machine top plate in the same line.
When bottle reaches to the mechanical holder detained filling station, Bottle sensor sense the bottles and Magnetic clutch starts to rotate which is mounted on auger shaft. It fills the desired amount of powder into the bottle through auger, where rotation time is previously determined.
Duly filled bottles go upward on to the sealing station with the help of SS conveyor belt.
Technical Specification:
| Model | ADF-50 |
| Production Rate | 20 to 50 Containers/Minute |
| Input Specification | |
| Container Diameter Container Height | 25mm to 90mm 36mm to 300mm |
| Filling Range | 5 gms. To 200 gms. In single stroke with the help of dosing time and/or with help of change parts. |
| Filling Accuracy | ±2% to 3.5% depending upon consistency & uniformity of powder. |
| Power Specification | 1.5 H.P., 3 Phase, 4 Wire System, 50 Hertz |
| Optional Accessories: | Pre/Post Nitrogen Purging Arrangement Aluminum Profile Cabinet Covering Full Machine |
| Overall Dimension | 1400mm (L) X 800mm (W) X 1900mm (H) |
