Send InquirySingle Stroke Ampoule Filling Machine
Product Details:
- Material SS 304
- Feature Food Medical Chemical
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
Single Stroke Ampoule Filling Machine Price And Quantity
- 1.500000 INR
- 1 Unit
Single Stroke Ampoule Filling Machine Product Specifications
- Human Machine Interface
- 380 Volt (v)
- No
- 100-200 Kilograms (kg)
- Silver
- 1 Year
- 220 Volt (v)
- Food Medical Chemical
- Semi-Automatic
- 1000x600x950 Millimeter (mm)
- SS 304
- Electric
Single Stroke Ampoule Filling Machine Trade Information
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America South America Eastern Europe Middle East Africa Central America Asia
- All India
Product Description
Having immense knowledge in the functional domain, we are able to manufacture and supply an excellent quality Single Stroke Ampoule Filling Machine. The offered machine is used for filling the ampoule in the container with perfection. Our provided machine is manufactured from pristine quality components and ultra-modern technology under the strict guidance of our experts. Available in several technical specifications, this Single Stroke Ampoule Filling Machine can be easily purchased from us at nominal price range.
Features:
-
Robust construction
-
Noise-free operations
-
Low power consumption
-
Minimum maintenance
Single Stroke Ampoule Filling Machine
Single Stroke Ampoule Filling Machine built on principle of slant travel of ampoules while filling and sealing, to take care of vide variation of ampoule neck dimensions, thicknesses of available standard ampoules.
The Filling unit built on S. S. Square pipe frame and totally encompassed with S. S. Coverings, in pleasing matt finish, Further, the large opening available at the bottom side for ease of absolute cleaning.
The pendant type electrical control panel is lifted from machine for ease of operation and safety.
Salient Features:
-
Compact GMP model.
-
All contact parts made from high quality Stainless Steel 316 & other Non-contact parts made from Stainless Steel 304.
-
Minimum change over parts from 1ml to 20ml ampoule size.
-
No Ampoule No Filling system.
-
Ampoule neck centering during gas flushing and filling operations.
-
Possibility of nitrogen gas flushing before, during and after filling.
-
Full accessibility allows easy maintenance.
-
Machine equipped with pre-warming station.
-
Minimum change over time, little maintenance & easy cleaning.
Technical Specification:
|
Model |
AFS-30 |
|
No. of Strokes |
Single |
|
Ampoule Handling Range |
1 ml to 20 ml |
|
Production Output |
15 to 30 ampoules/minute |
|
Filling Accuracy |
+1% |
|
Require Gas for Sealing |
LPG & Oxygen (O) |
|
Nitrogen Flushing |
Pre & Post Nitrogen Flushing Available |
|
Power Specification |
0.5 H.P. |
|
Electrical Characteristics |
230 Volts, Single Phase, 50 Hertz, 4 Wire System |
|
Contact Parts |
Made from Stainless Steel 316L |
|
Non Contact Parts |
Made from Stainless Steel 304 |
|
Overall Dimension |
915mm (L) x 610mm (W) x 965mm (H) |
