Pilot Scale Multi Mill

Pilot Scale Multi Mill

Pilot Scale Multi Mill is a self contained portable unit useful for high speed granulating, pulverising, mixing, shredding and chopping of wide range of wet and dry materials without special attachments.

As compared to the four common principles of size reduction i.e. grinding, compression, impact and shearing, which often do not produce controlled size reduction, this machine utilizes the principle of variable force swing hammer blades having both knife and impact edges rotating with a carefully selected screen to control size reduction.

Flow path of material in vertical rotor machine is streamlined. During comminution, material entering the chamber travels to the periphery and passes through the screen tangentially and radially, avoiding chocking and temperature rise.

Salient Features

GMP Model with all contact Parts made of Stainless Steel 316 quality material.

All contact parts can be easily and quickly dismantled and cleaned.

Castores provided for the ease of mobility.

Sieves available in sizes of 0.5 to 12 mm hole dia.

12 nos. beaters with knife edges,impact edges & 02 nos. scrapper blades.

AC Frequency Drive and Belt-less drive & online granulation model available.

Suitable for dry and wet granules.

Process Operation

Multi Mill is designed to utilize the principle of variable force swing beaters having both knife and impact edges rotating within a selected screen to control the particle reduction. Material fed in to the processing chamber moves to the periphery and passes through the screen radially and tangentially. Finally the processed material gets collected in to the container kept below the processing chamber.

Technical Specification

Power Supply                                              3 H.P.

Electrical Characteristics                             440 Volts, 3 Phase, 1440 RPM

D.O.L.

(Starter provided with reversible switch.)     89 mm ( approximate )

Rotor Diameter

Rotor RPM                                                    750 / 1400 / 2200 / 2800 ( approximate )

Screen Diameter                                           260 mm

Blades                                                          12 nos. With Knife & Impact Edges & 02 nos. Scraper Blades

Out put                                                         25 to 175 Kgs/Hour
