Send InquiryHigh Speed Ampoule Filler
Product Details:
- Material Stainless Steel
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
- Voltage 220 Volt (v)
High Speed Ampoule Filler Price And Quantity
- 1 Unit
- 3.500000 INR
High Speed Ampoule Filler Product Specifications
- 220 Volt (v)
- 650 x 965 x 1200 Millimeter (mm)
- Silver
- 220 Volt (v)
- Electric
- Stainless Steel
- 100-200 Kilograms (kg)
- Human Machine Interface
- 1 Year
- No
- Semi-Automatic
High Speed Ampoule Filler Trade Information
- Nhava Sheva
- Cash Advance (CA) Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Eastern Europe Africa Middle East South America Australia Asia Central America North America
- All India
Product Description
High Speed Ampule Filler SealerHigh Speed Ampule Filler Sealer built on principle of slant travel of ampules while filling and sealing, to take care of vide variation of ampule neck dimensions, thicknesses of available standard ampoules.
The Filling unit built on Stainless Steel Square pipe frame and totally encompassed with Stainless Steel Coverings, in pleasing mat finish, Further, the large opening available at the bottom side for ease of absolute cleaning.
The pendant type electrical control panel is lifted from machine for ease of operation and safety.
Salient Features :
Compact GMP model.
All contact parts made from high quality Stainless Steel 316L & other Non-contact parts made from Stainless Steel 304.
Minimum change over parts from 1ml to 10ml ampule size.
"No Ampoule - No Filling" system.
Ampoule neck centering during gas flushing and filling operations.
Possibility of nitrogen gas flushing before, during and after filling.
Full accessibility allows easy maintenance.
Machine equipped with pre-warming station.
Minimum change over time, little maintenance & easy cleaning.
Technical Specification :
| Model | AFS-200 |
| No. of Head | Eight |
| Ampoule Handling Range | 1 ml to 10 ml |
| Production Output | 100 to 200 ampules/minute |
| Filling Accuracy | +1% |
| Require Gas for Sealing | LPG & Oxygen |
| Nitrogen Flushing | Pre & Post Nitrogen Flushing Available |
| Power Specification | 1 H.P. |
| Electrical Characteristics | 230 Volts, Single Phase, 50 Hertz, 4 Wire System |
| Contact Parts | Made from Stainless Steel 316L |
| Non Contact Parts | Made from Stainless Steel 304 |
| Overall Dimension | 2700mm (L) x 1600mm (W) x 1785mm (H) |
