Crushable Ampule Filler Sealer Machine

Ampoule Filling  Machine  is uses for the filling and sealing of glass ampoules. Ampoule Filling Machine uses to fill and seal 1ml, 2ml, 3ml, 5ml, 10ml, 20ml & 25ml glass ampoules. This Automatic Ampoule Filling Sealing Machine is uses in pharmaceutical, cosmetic, chemical and agriculture industry for perfect filling of ampoules.

We are having machines to fill open mouth ampoules as well as closed mouth ampoules.

Salient Features:-

• Compact cGMP filling machine.

• Different models available suitable as per individual customer's requirements.

• All contact parts made from High Quality Stainless Steel 316L & Non-contact parts made from Stainless Steel 304.

• Minimum change over parts from 1ml to 10ml ampoule size.

• “No Ampoule – No Filling” system.

• Ampoule neck centering during gas flushing and filling operations.

• Possibility of nitrogen gas flushing before and after filling.

• Full accessibility allows easy maintenance.

• Machine equipped with pre-warming station.

• Flow Meters for regulating flames easily.

•  Minimum change over time, little maintenance, easy cleaning.

Process Operation:-

 Empty washed & sterilized ampoules receive automatically on wire mesh conveyor belt from outfeed of sterilizing tunnel. Ampoule fed automatically into in-feed hopper from the left hand side of the machine and feed to receiving rack through cassette. The moving rack which moves horizontally collect four ampoules from the receiving rack and transfer the ampoule to the machine in left to right in an inclined position through pre-gassing. Pre-gassing, Filling, Post Gassing, Pre-heating & sealing station.

Technical Specification:-

Note: Electrical characteristics can be adjusted as per customer's domestic power requirements.
