Send InquiryCrushable Ampoule Filler
Product Details:
- Material MS / SS
- Voltage 380 Volt (v)
- Power 220 Volt (v)
- Weight (kg) 100 Kilograms (kg)
- Dimension (L*W*H) 1000x600x950 Millimeter (mm)
- Color Sliver
- Warranty 1 Year
Crushable Ampoule Filler Price And Quantity
- 1 Unit
- 1.500000 INR
Crushable Ampoule Filler Product Specifications
- MS / SS
- 1000x600x950 Millimeter (mm)
- 380 Volt (v)
- Sliver
- 100 Kilograms (kg)
- 1 Year
- 220 Volt (v)
Crushable Ampoule Filler Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe North America South America Eastern Europe Central America Africa Australia Asia
- All India
Product Description
Crushable Ampoule Filler
Ampoule Filler is uses for the filling and sealing of glass ampoules. Ampoule Filling Machine uses to fill and seal 1ml, 2ml, 3ml, 5ml, 10ml, 20ml & 25ml glass ampoules. This Automatic Ampoule Filling Sealing Machine is uses in pharmaceutical, cosmetic, chemical and agriculture industry for perfect filling of ampoules.
We are having machines to fill open mouth ampoules as well as closed mouth ampoules.
Salient Features:-
- Compact cGMP filling machine.
- Different models available suitable as per individual customer's requirements.
- All contact parts made from High Quality Stainless Steel 316L & Non-contact parts made from Stainless Steel 304.
- Minimum change over parts from 1ml to 10ml ampoule size.
- “No Ampoule No Filling system.
- Ampoule neck centering during gas flushing and filling operations.
- Possibility of nitrogen gas flushing before and after filling.
- Full accessibility allows easy maintenance.
- Machine equipped with pre-warming station.
- Flow Meters for regulating flames easily.
- Minimum change over time, little maintenance, easy cleaning.
Technical Specification:-
Model | AFS-30 | AFS-55 | AFS-100 |
Production Output | 15 to 30 Ampoules/Minute | 30 to 55 Ampoules/Minute | 60 to 100 Ampoules/Minute |
No. of Filling & Sealing Heads | Single | Two | Four |
Filling Range | 1ml to 20ml | 1ml to 25ml | 1ml to 10ml |
Input Specification | - | - | - |
Ampoule Diameter | 9mm to 18mm | 9mm to 22.5mm | 9mm to 17mm |
Ampoule Height | 50mm to 120mm | 50mm to 130mm | 50mm to 95mm |
Filling Accuracy | ± 0.5% - 1% | ± 0.5% - 1% | ‚± 0.5% - 1% |
Power Supply | 0.25 H.P. | 0.5 H.P. | 1 H.P. |
Electrical Characteristics | 220 Volts, Single Phase, 50 Hertz | 220 Volts, Single Phase, 50 Hertz | 220 Volts, Single Phase, 50 Hertz |
Utility | - | - | - |
Nitrogen Pressure | 1kg/Cm² | 1kg/Cm² | 1kg/Cm² |
Oxygen Pressure | 1kg/Cm² | 1kg/Cm² | 1kg/Cm² |
LPG Pressure | 0.5 kg/Cm² | 0.5 kg/Cm‚² | 0.5 kg/Cm² |
Overall Dimension | 915mm (L) x 610mm (W) x 965mm (H) | 915mm (L) x 760mm (W) x 965mm (H) | 1200mm (L) x 1070mm (W) x 965mm (H) |
Note: Electrical characteristics can be adjusted as per customer's domestic power requirements.
