Send InquiryCompact Vial Washer
Product Details:
- Material Stainless Steel
- Computerized No
- Voltage 50 Volt (v)
- Power 220 Volt (v)
- Weight (kg) 100-200 Kilograms (kg)
- Dimension (L*W*H) 2550 x 1050 x 1550 Millimeter (mm)
- Color Sliver
Compact Vial Washer Price And Quantity
- 1.500000 INR
- 1 Unit
Compact Vial Washer Product Specifications
- 2550 x 1050 x 1550 Millimeter (mm)
- Sliver
- No
- 100-200 Kilograms (kg)
- 50 Volt (v)
- Stainless Steel
- 1 Year
- 220 Volt (v)
Compact Vial Washer Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Central America Eastern Europe Africa Middle East South America Australia Asia North America
- All India
Product Description
Features:
- Impeccable performance
- Excellent functionality
- Low maintenance
- Rust proof body
Salient Features:
- Positive & pressurized jets through washing needle for pressure cleaning at minimum usages for washing media.
- Sound design concept of pressure tank for reverses & continuous supply of washes medias.
- Both internal & external washing ensuring absolutely & continuous ampoule / vial after sequential washing.
- Acrylic top cover for clear view of washing events taking place in the machine
- On-line poly carbonates housing with P.P. replaceable filter cartridge of 5 OR 10 micron of water for best possible washing.
- All contact parts of washing media are of S.S.
- In the event of acrylic cover lifted during cycle operation, the machine will automatically stop and re-start from the point when cover is pushed down.
Process Operation:-
The dump loading procedure may be used, if ampoules/vials are received in ready to dump boxes, which will have exactly into the same number of ampoule/vial and the pitch, as loading tray. Alternatively, each ampoule/vial has to be arranged into the tray. The loading tray/s is placed directly into the machine & the handle bar is lowered for ampoule/vial for automatic centering of washing needles into the ampoule/vial mouths. The top cover is also lowered & switch is operated for automatic sequent
Washing Cycle:-
- 1st wash DM water
- 2nd wash Purified Air
- 3rd wash DM water
- 4th wash Purified Air
- 5th wash Distilled Water (WFI)
- 6th wash Purified Air
Technical Specification:-
| Model: | AAVW-340 |
| Production Rate | 30 to 110 Vials/Min. |
| - | 90 to 160 Ampoules/Min. |
| Input Specification | - |
| Ampoule Dia: | 10mm to 21.5mm |
| Ampoule Height: | 60mm to 140mm |
| Vial Dia.: | 15mm to 56mm |
| Vial Height: | 56mm to 110mm |
| Power Specification | 0.25 H.P. |
| Electrical Characteristics | 440 Volts, 3 Phase, 4 Wire System, 50 Hertz |
| Utility | - |
| Distilled Water: | 2 kg/cm² |
| Air: | 20 CFM @ 5 bar |
| Overall Dimension | 990mm (L) X 860mm (W) X 940mm (H) |
