Capsule Orienter

Capsule Orienter

The equipment has been as ideal for medium/large scale pharmaceutical companies. The equipment is simple to operate it save time and labor. The automatic capsule loader is compact occupies minimum space; it gives higher production with much better standard of accuracy.

Advantage :

Loader automatically loads empty capsule in the loading plate for manually operated capsule filling machine, hence it take normally 5 minutes to load empty capsule in 300 holes loading plate manually, this machine cuts down that time to only 30 second. It supplied filled loading plates for 2-3 capsule filling machine. Thus increase the production on one hand and reduce the number of operator on other hand.

Production Output :

Fill 300- holes plate in 30 seconds give an output of 36,000 capsule per/hour

Interchangeability

The machine is manufactured to suit the following capsule size combination 00/0/1/2/3 or 4/5

Automatic Capsule Loader is as ideal choice for medium & large scale pharmaceutical companies. This 300 Holes Automatic Capsule Loader uses to fill plates of Manual Capsule Filling Machine. The equipment is simple to operate and time & labor saver. The automatic capsule loader is compact occupies minimum space; it gives higher production with much better standard of accuracy.

Salient Features :

• Low investment high output.
• Significant difference in your production department.
• Simple to operate, can be handled by semi skilled person.
• No setting system for any change part.
• Machine stop automatically after loading is complete.

Technical Specification :
