Send InquiryAutomatic Vial Filling Machine
Product Details:
- Material Stainless Steel
- Voltage 380 Volt (v)
- Power 415 Volt (v)
- Weight (kg) 400-600 Kilograms (kg)
- Dimension (L*W*H) 1300X500X1200 Millimeter (mm)
- Color Sliver
- Warranty 1 Year
Automatic Vial Filling Machine Price And Quantity
- 1 Unit
- 2.3500000 INR
Automatic Vial Filling Machine Product Specifications
- Stainless Steel
- Sliver
- 415 Volt (v)
- 380 Volt (v)
- 400-600 Kilograms (kg)
- 1 Year
- 1300X500X1200 Millimeter (mm)
Automatic Vial Filling Machine Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Cash Advance (CA) Telegraphic Transfer (T/T) Cash in Advance (CID)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America Eastern Europe Africa Middle East South America Asia Central America
- All India
Product Description
Automatic Vial Filling & Rubber Stoppering Machine is compact model uses for the filling & rubber stoppering of injectable liquid vials. Adinath offers different models of Vial Filling & Rubber Stoppering Machine suitable for pharmaceutical industry. Our Automatic Six Head Vial Filling & Rubber Stoppering Machine provides output up to 9000 vials/hour suitable for large batch production, Our Automatic Four Head Vial Filling & Rubber Stoppering Machine provides output up to 7200 vials/hour suitable for medium batch production and Our Automatic Two Head Vial Filling & Rubber Stoppering Machine which provides output up to 3600 vials/hour suitable for medium & small batch productions. Our Vial Filling Machines are easy to operate & complies as per cGMP standards. Our standard machine equipped with stainless steel piston pump for the liquid filing, further we can also provide peristaltic pump for higher filling accuracy upon specific customer request.
Salient Features:-
- No cross contamination.
- Suitable for the filling Volume of 2ml to 250ml.
- Piston pump/Peristaltic pump aseptic filling.
- Filling with accuracy of ±0.5-1%.
- Easy to validate filling system for small/large batch production.
- All Contact Parts Made from S.S 316L & framework by S.S. 304.
- Variable A.C. frequency drive for speed adjustment Digital Vial Counter for counting production output.
- In-feed Turn Table/ Unscramble for automatic feeding of objects.
- On-line Mechanism.
- No Vial - No Filling" system.
- No Vial - Machine Stop" system.
Technical Specification:-
| Model | ALVF-60 | ALVF-120 |
| No of Filling Head | Two | Four |
| Production Rate | 30 to 60 Vials/Minute | 60 to 120 Vials/Minute |
| Input Specification: | - | - |
| Container Diameter: | 15mm to 70mm | 15mm to 70mm |
| Container Height: | 25mm to 140mm | 25mm to 140mm |
| Rubber Stopper: | 13mm, 20mm & 28mm Butyl with the help of change part | 13mm, 20mm & 28mm Butyl with the help of change part |
| Filling Range | 2ml to 250ml | 2ml to 250ml |
| Filling Accuracy | ±0.5-1% | ±0.5-1% |
| Power Supply | 1 H.P. | 1 H.P. |
| Electrical Characteristics | 380-440 Volts, 3 Phase, 50 Hertz, 4 Wire System | 380-440 Volts, 3 Phase, 50 Hertz, 4 Wire System |
| Optional Accessories | Programmable Logic Control (System) with MMI | Programmable Logic Control (System) with MMI |
| - | Safety Cabinet covering full machine | Safety Cabinet covering full machine |
| Overall Dimension | 1900mm(L) x 800mm(W) x 1680mm (H) | 2000mm(L) x 850mm (W) x 1680mm (H) |
