Send InquiryAutomatic Funnel Type Bottle Filling Machine
Product Details:
- Material Stainless Steel
- Computerized No
- Drive Type Electric
- Power 220 Volt (v)
- Voltage 240 Volt (v)
- Weight (kg) 100-150 Kilograms (kg)
- Dimension (L*W*H) 900X870X1950 Millimeter (mm)
Automatic Funnel Type Bottle Filling Machine Price And Quantity
- 1 Unit
- 100000.00 - 200000.00 INR
Automatic Funnel Type Bottle Filling Machine Product Specifications
- 100-150 Kilograms (kg)
- 900X870X1950 Millimeter (mm)
- Silver
- 220 Volt (v)
- No
- Stainless Steel
- 1 Year
- 240 Volt (v)
- Electric
Automatic Funnel Type Bottle Filling Machine Trade Information
- Nhava Sheva
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America Eastern Europe Central America Africa Middle East South America Asia
- All India
Product Description
Automatic Funnel Type Bottle Filling Machine
Automatic Funnel Type Dry Syrup Powder Filling Machine is a compact model uses for the filling of Dry Syrup Powder in to bottle.
Salient Features
-
Compact cGMP model.
-
All parts coming in contact with powder are made of Stainless Steel 316L.
-
No Bottle No Filling system eliminates wastage of costly powder.
-
Conveyor driving is through High quality imported Gear motor.
-
Machine speed can be adjusted by A.C. Frequency drive, which is time saving.
-
Machine is provided with delrin conveyor belt to avoid sticking of vial on conveyor.
-
Single track bottle movement, reduces setting of supporting guide rails and semi skilled person can also easily operate the machine.
-
Pneumatic bottle holding system is connected with auger rotation, which eliminates chances of bottle transfer before completion of filling operation.
-
Total PLC control for the machine.
-
No change parts are required for any change in bottle diameter from 30 to 120 ml.
Technical Specification
| Model No. : | APF-80 |
| Production Rate : | 40 to 80 Bottles/Minute |
| Fill Capacity : | 10 grms to 50 grms. (with different set of Auger and funnel) Fill range depending upon Bottle opening and bulk density of powder. |
| Accuracy | ±2% depending upon consistency and the Uniformity of bulk density of powder Under controlled level of Humidity (i.e. 35%) |
| Electrical Supply | 1 H.P. for Main Drive 0.25 H.P. for Conveyor |
| Power Requirement : | 440 Volts, 3 Phase, 50 Hertz |
| Height of Conveyor: | Adjustable from 850mm to 900mm |
| Dimensions: | 2200mm (L) x 1100mm (W) x 1800mm (H) |
| Net Weight | 450 kgs. |
| Gross Weight | 650 kgs. |
