Ampoule Washing & Drying Machine

Product Description

Ampoule Washing & Drying Machine

Description:-


Ampoule Washing & Drying Machine is designed to wash the outer surface of round shaped Ampouless. Machine washes the outer sides of Ampouless and eliminates the particles that are formed on the Ampouless, which are previously filled and sealed.


Salient Features:-


     Complete cGMP model

     Suitable for Ampoules sizes from 1ml to 20ml without any change parts (No change parts required)

    “No Ampoules  No Washing system eliminates wastage of water & air

     Easy cleaning & maintaining

     Machine is equipped with PLC system.

     Stops supply of water & air when acrylic doors opened during operation.

     Indication & alarm in PLC.

     Normal water required for washing & no hot water required

     When there is no Ampoules on conveyor, it stops the water & air supply. Infeed & outfeed Turn Tables.

     Imported Gear motor for main drive, unscrarnbler and scrambler

     Variable A.C frequency drive for main drive, unscrambler and scrambler Acrylic cabinet for machine.

Process Operation:-


Form the in feed Tray the Ampouless are fed into the External the Ampoules Washing Machine conveyors. The machine consists of two conveyors on which the Ampouless are properly fed and transported from in feed tray for the washing operation. Two Operations are carried out on this machine. First the Ampouless are washed by water jet and then dried by air jet. On the conveyor a set of spray nozzles are fitted on each on each conveyor for water Jet. One set of knife blocks are provided on each conveyor for air. The air sprayed through this knifes . The knifes are fitted in a inclined manner which ensures that is sprayed reaches each corner of the Ampoules which are previously washer. After washing and drying the Ampouless are guided to the out feed turn Table. Before reaching the out feed Turn Table a special arrangement is provided to dry the Ampoules from the bottom side . A set of Syringes are provided on the sides of each conveyor at the exit end which sprays the air jet on the bottom part of Ampoules resulting in the drying of the Ampouless This machine is completely operated by PLC . A covering of Acrylic cabinet is provided in the machine which when opened up during the operation immediately stops the supply of water &air and shows the indication which alarm in the PLC.

Technical Specification:-
