Send Inquiry5ml Ampoule Filling Machine
Product Details:
- Material SS 304
- Feature Chemical Food Medical
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
5ml Ampoule Filling Machine Price And Quantity
- 1.500000 INR
- 1 Unit
5ml Ampoule Filling Machine Product Specifications
- Silver
- 100-200 Kilograms (kg)
- Electric
- SS 304
- No
- 220 Volt (v)
- 1300x1700x750 Millimeter (mm)
- 380 Volt (v)
- 1Year
- Semi-Automatic
- Chemical Food Medical
- Human Machine Interface
5ml Ampoule Filling Machine Trade Information
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia South America Eastern Europe Middle East Central America Africa Asia North America
- All India
Product Description
Ampoule Filling Sealing Machine built on principle of slant travel of ampoules while filling and sealing, to take care of vide variation of ampoule neck dimensions, thicknesses of available standard ampoules.
The Filling unit built on S. S. Square pipe frame and totally encompassed with S. S. Coverings, in pleasing mat finish, Further, the large opening available at the bottom side for ease of absolute cleaning.
The pendant type electrical control panel is lifted from machine for ease of operation and safety.
Salient Features :
Compact GMP model.
All contact parts made from high quality Stainless Steel 316 & other Non-contact parts made from Stainless Steel 304.
Minimum change over parts from 1ml to 20ml ampoule size.
No Ampoule - No Filling system.
Ampoule neck centering during gas flushing and filling operations.
Possibility of nitrogen gas flushing before, during and after filling.
Full accessibility allows easy maintenance.
Machine equipped with pre-warming station.
Minimum change over time, little maintenance & easy cleaning.
Technical Specification :
| Model: | AFS-55 | AFS-100 |
| Production Output | 30 to 55 Ampoules/Minute | 60 to 100 Ampoules/Minute |
| No. of Filling & Sealing Heads | Two | Four |
| Filling Range | 1ml to 20ml | 1ml to 10ml |
| Input Specification | - | - |
| Ampoule Diameter | 9mm to 17mm | 9mm to 17mm |
| Ampoule Height | 50mm to 95mm | 50mm to 95mm |
| Filling Accuracy | ± 0.5% - 1% | ± 0.5% - 1% |
| Power Supply | 1 H.P. | 1 H.P. |
| Electrical Characteristics | 220 Volts, Single Phase, 50 Hertz | 220 Volts, Single Phase, 50 Hertz |
| Utility | - | - |
| Nitrogen Pressure | 1kg/Cm² | 1kg/Cm² |
| Oxygen Pressure | 1kg/Cm² | 1kg/Cm² |
| LPG Pressure | 0.5 kg/Cm² | 0.5 kg/Cm² |
| Overall Dimension | 915mm (L) x 760mm (W) x 965mm (H) | 1200mm (L) x 1070mm (W) x 965mm (H) |
