Send Inquiry1ml to 25ml Ampoule Filling Machine
Product Details:
- Material Stainless Steel
- Feature Food Medical Chemical
- Computerized No
- Automatic Grade Semi-Automatic
- Control System Human Machine Interface
- Drive Type Electric
- Power 220 Volt (v)
1ml to 25ml Ampoule Filling Machine Price And Quantity
- 100000.00 - 200000.00 INR
- 1 Unit
1ml to 25ml Ampoule Filling Machine Product Specifications
- 220 Volt (v)
- Food Medical Chemical
- Electric
- No
- Semi-Automatic
- 100-200 Kilograms (kg)
- Human Machine Interface
- Silver
- Stainless Steel
- 380 Volt (v)
- 1 Year
- 1000x600x950 Millimeter (mm)
1ml to 25ml Ampoule Filling Machine Trade Information
- Letter of Credit (L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cash Advance (CA)
- 4 Unit Per Month
- 4 Week
- Wooden Box.
- Western Europe Australia North America Eastern Europe Central America Africa Middle East South America Asia
- All India
Product Description
1ml to 25ml Ampoule Filling MachineAutomatic Ampoule Filling Sealing Machine is suitable to fill 1ml to 20ml ampoules. Machine designed for performance and GMP demanding customers. The machine built on principal of slant travel of ampoules while filling and sealing to take care of video variation of neck dimensions, thickness and ovality of available ampoules. The unit built on S.S. Square pipe frame and totally encompassed with S.S. Coverings in pleasing mat finish. Further large opening available at bottom side for ease of absolute cleaning.
Salient Features :
- Compact cGMP model.
- Higher output up to 6000 Ampoules per hour.
- All contact parts made from High Quality Stainless Steel 316L & Non-contact parts made from Stainless Steel 304.
- Minimum change over parts from 1ml to 10ml ampoule size.
- "No Ampoule - No Filling" system.
- Ampoule neck centering during gas flushing and filling operations.
- Possibility of nitrogen gas flushing before, during and after filling.
- Full accessibility allows easy maintenance.
- Machine equipped with pre-warming station.
- Flow Meters for regulating flames easily.
- Minimum change over time, little maintenance, easy cleaning
Technical Specification :
| Model: | AFS-55 |
| Production Output | 30 to 55 Ampoules/Minute |
| No. of Filling & Sealing Heads | Two |
| Filling Range | 1ml to 20ml |
| Input Specification | - |
| Ampoule Diameter | 9mm to 17mm |
| Ampoule Height | 50mm to 95mm |
| Filling Accuracy | ± 0.5% - 1% |
| Power Supply | 1 H.P. |
| Electrical Characteristics | 220 Volts, Single Phase, 50 Hertz |
| Utility | - |
| Nitrogen Pressure | 1kg/Cm² |
| Oxygen Pressure | 1kg/Cm² |
| LPG Pressure | 0.5 kg/Cm² |
| Overall Dimension | 915mm (L) x 760mm (W) x 965mm (H) |
